N-BEGELLO

PRODUCT HIGHLIGHTS OF NBE PALLETISATION GRADES BENTONITE.
IMPORTANT CHARACTERISTICS OF N-BEGELLOBENTONITE FOR CIVIL ENGINEERING AND PILLING APPLICATIONS.
  • Largesurfacearea with high swelling and good thixotropic properties.
  • Goodplasticity & lubricity with Highshearandcompressivestrength.
  • Lowfilterloss,Highviscosity,Impermeability&Lowcompressibility.
N-BEGELLO is pure naturally occurring Sodium based Bentonite contains alwaysmorethan85%Smectite.
N-BEGELLO is having excellent gel strength properties while the fluid is at itsrest.
N-BEGELLO Piling GradeBentonite is widely used in the Construction of large diameter bored piles.

TYPICAL CHEMICAL ANALYSIS OFN-BEGELLO BENTONITE

SiO2 48–52 Al2O3 14–18
Fe2O3 12–16 CaO 1.0–2.0
Na2O 2.0-3.5 MgO 1.5–3.0
TiO2 1.0–2.5 K2O 0.1–0.5
S 0.1-0.2 LOI 7.0-10.0
GRADES OF N BEGELLOBENTONITE FOR CIVIL ENGINEERINGPROJECTS

N-BEGELLO - N       AsperOCMA-DFCP-4specifications.

N-BEGELLO - B       Bentonitewithyieldmorethan150bbls/ ton.


  • N-Begello-N

    N-BEGELLO NBentonite is pure high swelling sodium based Bentonite mined and processed in northwest part of Kutch, Gujarat, India. It offers superior performance than API/OCMA specifications.It contains more than 85% Smectite and the active clay content isdetermined by colloid and x-ray diffraction.Givinghigher yield and lower fluid loss hence widely used inDrilling and Civil Engineering Industries.And because of its purity resist Ionic solution and has better resistance to high and low PH solutions.

    N-BEGELLO NBentoniteisusedforsuperiorperformanceinDrillingMuds,Bore-PilingandGrouting,Soilsealantfor impermeable barriersforland,Sanitarylandsfills,Hazardouswaste sites, Sewagelagoons, Diaphragmwalls andCementBentoniteSlurries.

    Typical performance of N-BEGELLO - Nwhen tested as per OCMA-DFCP-4
    Properties Unit OCMA Requirement N-BEGELLO - N
    Yield M3/Ton 16.0min. 16.0–20.0
    FluidLoss Ml 15.0max. 12.0–15.0
    SandContent %bywt. 2.5max. 1.0–2.5
    Drymeshpassing 100 mesh %bywt. 98.0min. 98.0-99.0
    Moisture %bywt. 15.0max. 10–15

    PACKING:

    LUMPS – Loose, 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

    POWDER - 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

    Environment:

    N-BEGELLO - NBentonite does not contain any fermentable product and is environmentally acceptable.

  • N-Begello-B

    N-BEGELLO – Bis natural high swelling Sodium Bentonite of exceptional purity. Mined and processed in Northwest part of Kutch India, it offers superior performance than API 13-A and OCMA specification. It is processed to give fine free flowing powder. Viscosifies rapidly when added to fresh water and one sack of 50kgs in 1000 litres of fresh water should give workable slurry and sealing properties. Contains more than 85% SMECTITE. The active clay content determined by Colloid content and Semi-quantitative X-ray Diffraction. Inferior grade Bentonite Chemically treated to meet specification may deteriorate with time and lose their effectivenesswhileN-BEGELLO – Bbecause of purity resists ionic solution and has better resistance to high and low PHsolution. N-BEGELLO – Bis usedforsuperiorperformancein Drilling Muds, Bore - Pilling and Grouting, Soil sealant to form impermeable barriers for land, Sanitary landfills, Hazardous waste sites, Sewage Lagoons, Cement Bentonite slurries and Diaphragm walls.

    N-BEGELLO – BDosages Kg/M3 Lbs/bbls
    NormalDrilling/Piling 30-40 10-15
    SoilStabilization 40-60 14-20

    Note: Barrelteston-sitesoilprovidesthebestmethodtodeterminecorrectN BEGELLO Bsoilmix.Propermixingandcompactionareessentialforgoodsealing.Prehydrationnecessaryifthefacility willholdotherthancleanwater.

    Typical Physical performance of N-BEGELLO - B

    MoistureContent % 10.0to13.0
    PH 9.0-10.5
    DryFinenesspassing75micron% 75 to90
    WetscreenRetention75 micron% 1.0 to3.0
    FreeSwellingValuecc 25+3
    LiquidLimit % 500-600
    MarshFunnelViscosity.Sec 30–60
    Colloids% 80 min.
    Yield 20.0to25.0M3/Ton

    TestMethod: AsperOCMA-DFCP-4testsmethodsandforyieldsuspensionof10gmsofN-BEGELLO - Bin350mlofwaterispreparedat13000rpminHamiltonbeach mixture.

    PACKING:

    LUMPS – Loose, 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

    POWDER - 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

    Environment:

    -BEGELLO - BBentonite does not contain any fermentable product and is environmentally acceptable.

N-BEPHARM

PRODUCT HIGHLIGHTS OF NBE IP GRADEBENTONITE.

IMPORTANT CHARACTERISTICS OF N-BEPHARMBENTONITE

  • N-BEPHARMis natural Bentonite of exceptional purity. It is mined and processed in North West part of India.
  • N-BEPHARMcan be used as binder, filler, conveyer, active ingredient etc.
  • N-BEPHARMhas high Montmorillonite content.
  • N-BEPHARMis the brilliant innovation from NBEwhich is economical and naturally ecological.
Typical Chemical analysis of N-BEPHARMBentonite
SiO2 48–52 Al2O3 14 - 18
Fe2O3 12 - 16 CaO 1.0 – 2.0
Na2O 2.0 - 3.5 MgO 1.5 - 3.0
TiO2 1.0 – 2.5 K2O 0.1 - 0.5
S Nil LOI 7.0-10.0
Physical analysis of N-BEPHARMBentonite
Moisture(%wt) 12 % Max 10.4
Particlesizefinerthan200mesh(%) 95 % min 97
pH 7 - 8.5 7.69
MBAValue (mg/gm) 300 mg/gm 340
PWA 300 % Min 370
BRIGHTNESS 50 min 56
VISCOSITY, 5 % SUSP. 4 cp min 7

  • Packing

    25 kgs bags, 50 kgs bags, 1000 kgsbig bags

  • Environment

    We are committed to keep our environment clean, safe and healthy.
    We will continue to promote greater environmental awareness in our daily activities. If we cannot sustain the Environment , we cannot sustain ourselves.
    Preservation of the environment is the responsibility of every employee.
    We shall create a World where the Environment does not need PROTECTION.

N-BEYOND

PRODUCT HIGHLIGHTS OF NBE PALLETISATION GRADEBENTONITE
IMPORTANT CHARACTERISTICS OF N-BEYONDBENTONITE

N-BEYOND is natural high swelling sodium based Bentonite of exceptional purity. It is mined and processed in North West part of India.

N-BEYOND is pure naturally occurring Sodium based Bentonite containing always morethan 80% Smectite. The high Montmorillonite content of N-BEYONDgives always high swelling value with excellent thermal stability.

N-BEYOND is the brilliant innovation from NBE which is economical, naturally ecological and above all quick bonding element.

N-BEYOND Bentonite is having excellent bonding with highwater absorption properties andiswidelyusedinironorepalletisation.

N-BEYOND Bentonite is available in Lumps and Powder form.

TYPICAL PHYSICAL &CHEMICAL ANALYSIS OFN-BEYONDBENTONITE

PHYSICALPERAMETERS
PHYSICALPROPERTIES TYPICALSPECIFICATION
1. Moistureat105–110`C 14.0% max
2. LumpsStructure(40mmPassing) 90% min
3. Powder structure (200Mesh Passing) 85% min
4. MethyleneBlueAbsorption(mg/gm) 390 min.
5. FreeSwellingCapacity (2gm/100cc distil water 30cc min
6. PWA(ASTM) % 650%min
7. 18“GreenDrop. No. 8 min
8. PH (2.0%Suspension) 9.0 min
9. Colloids% 75.0min.
CHEMICALCOMPOSITION
1. SiO2% 48-52%
2. Al2O3% 14–18%
3. Fe2O3 % 14.0-18.0%
4. CaO% 0.5–1.5 %
5. Na2O% 2.0-3.2%
6. TiO2% 1.5–2.5%
7. K2O% 0.1–0.5%
8. MgO% 2.0-4.0%
9.LOI % 6.0–9.0%

  • Packing

    LUMPS - Loose, 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

    POWDER - 25 kgs bags, 50 kgs bags, 1000 kgs big bags.

  • Environment

    We are committed to keep our environment clean, safe and healthy.
    We will continue to promote greater environmental awareness in our daily activities. If we cannot sustain the Environment , we cannot sustain ourselves.
    Preservation of the environment is the responsibility of every employee.
    We shall create a World where the Environment does not need PROTECTION.
